OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL
3-40 Published 02-21-2019, Control # 611-05
Set control lever characteristic curve menu
This menu allows the operator to set the amount of stroke
the control levers require to initiate a response.
1)
Optional equipment
FIGURE 3-36
8882-17b
1 2
3 4
5
6
Item Description Refer to
1 Swing function curve page 3-90
2 Boom function curve page 3-90
3 Main hoist curve page 3-90
4
Luffing boom extension
function curve
(1
page 3-90
5
Auxiliary hoist function
curve
(1
page 3-90
6 Reset function curves page 3-90
