Manitowoc Grove TMS9000-2 Series User Manual

OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL
3-128 Published 02-21-2019, Control # 611-05
mounted, or at 0 degrees if a counterweight is
mounted.
Exiting OPT Screen
To exit this screen, press the ESC button on the remote
control. The main screen appears.
Information
To access the information screen, press the info button
on the remote control
See Figure 3-181
The information screen shows the following:
• Remote control’s software version (1)
You will need to know the software version when
communicating with your Grove dealer or Manitowoc
Crane Care.
• Crane Serial Number (2)
The remote control must remain with the crane it was
supplied with. The serial number in the information
screen must match the serial number on the crane.
Rated capacity limiter (RCL)
Control unit control console
Exiting the menu/input mode
Entering values
The input mode for the RCL code is switched on.
FIGURE 3-181
Press
button (1):
The opened menu is closed – the main
menu is opened (Figure 3-182)
Input mode is deactivated
Press
button (2):
The opened menu closes – the menu from
the next higher level is opened
Input mode is deactivated
1
To the right (Figure 3-183): Next greater value
To the left: Next smaller value
Slowly turning – changes the
value gradually
Hold down and turn – quick
value change
or
2 Next greater value
3 Next smaller value
FIGURE 3-182
8854-194
