Manitowoc Grove TMS9000-2 Series User Manual

Grove Published 02-21-2019, Control # 611-05 3-141
TMS9000-2 OPERATOR MANUAL OPERATING CONTROLS AND INDICATORS
3
LIGHTING, WINDSHIELD WIPER/WASHING
SYSTEM
Lighting
Superstructure Cab Work Lights on/off
Boom Lights
Rotating Boom Lights Control
Cab lighting
Reading lamp
To switch
on:
Push down – lamp in the button on
(Figure 3-219)
To switch
off:
Push up – lamp in the button off
To switch
on:
Push down – lamp in the button on
(Figure 3-220)
To switch
off:
Push up – lamp in the button off
FIGURE 3-219
8854-239
FIGURE 3-220
8854-240
Down: Push down (Figure 3-221)
Up: Push up
1 Always on (Figure 3-222)
2 Always off
3 On/off via door contact
1On
2Off
FIGURE 3-221
8854-241
FIGURE 3-222
8854-242
FIGURE 3-223
8854-243
