Grove Published 02-21-2019, Control # 611-05 3-3
TMS9000-2 OPERATOR MANUAL OPERATING CONTROLS AND INDICATORS
3
CARRIER CAB CONTROLS AND
INDICATORS
See Figure 3-4
7
9
11
8864
FIGURE 3-1
1
2
3
4
5
6
8
10
12
1. Transmission Shift Lever
2. Spare
3. Spare
4. Spare
5. USB Ports
6. 12 Volt Outlet
7. Fire Extinguisher
8. Horn
9. Turn Signal/High Beam-Low Beam Lever
10. Steering Column Tilt and Telescope Ad-
justment Lever
11. Cab Circulating Fan
12. Windshield Wiper and Washer
13. Camera Display
14. Dome Light and Switch
15. Air Horn Control
16. Throttle Pedal
17. Brake Pedal
18. Clutch Pedal Location
13
14
15
16
17
18
