OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL

3-88 Published 02-21-2019, Control # 611-05

Outrigger rigging code verification

This is the screen that will be displayed after the operator

accepts a new rigging code if the measured outrigger

positions do not match the required outrigger positions. The

rigging code and required outrigger positions are shown on

the left. The actual positions are shown on the right, and are

red if they do not match the required positions.

If the outrigger positions match the rigging code selected this

screen is skipped and the display goes directly from the

setup screen to the main operating screen.

When on this screen the operator has the choice between

the check mark to confirm awareness of the difference in

actual outrigger position to that required for the rigging code,

or using the X to return to select a new rigging code.

Adjusting the wiper stroke interval of the

windshield wiper

You can set a value between 3 and 30 seconds for the front

and roof window wiper stroke interval.

NOTE: The higher the selected value is, the longer the

pauses between the strokes of the wiper are.

Select and confirm the symbol (1, Figure 3-88).

The Windshield wiper menu opens.

FIGURE 3-87

8883-2

Item Description

1 Rigging code

2 Required outrigger positions

3 Measured outrigger positions

4 Accept rigging code

5 Reject rigging code

9088

FIGURE 3-88

Manitowoc Grove TMS9000-2 Series User Manual
