TMS9000-2 OPERATOR MANUAL OPERATING CONTROLS AND INDICATORS
3
1)
Optional equipment
Item Description Refer to
1 Rigging code number page 3-131
2
Current swing angle
display
page 3-134
3 Current overall height
4
Current auxiliary hoist
reeving
1)
page 3-130
5 Current main hoist reeving page 3-130
6
Current degree of
utilization display
page 3-135
7 Weight of the rigging
8 Current weight of the load page 3-134
9 Allowable maximum load page 3-135
10 Outrigger span display page 3-134
11 Current inclination page 3-96
12 Current telescoping status page 3-105
13 Current working radius
14 Current counterweight page 3-49
15 Current main boom angle page 3-134
16 Current main boom length page 3-105
17
Lattice extension angle
1)
page 3-134
18
Current wind speed
1)
page 3-96
