Manitowoc Grove TMS9000-2 Series User Manual

4-23
TMS9000-2 OPERATOR MANUAL OPERATING PROCEDURES
4
Published 02-21-2019, Control # 611-05
GROVE
Axle Weight Distribution Table
Axle Weight Distribution Table
Description
C G T o C L
R e a r B o g i e
cm (in)
W e i g h t
kg (lb)
F r o n t A x l e
kg (lb)
R e a r A x l e
kg (lb)
Maximum Tire & Wheel Loads
Allowed
23224 (51200) 27216 (60000)
Maximum Axle Loads Allowed 23224 (51200) 27216 (60000)
Standard Carrier Assy (8x4x4) 286.39 (112.75) 19233 (42400) 9795 (21595) 9437 (20805)
“Superstructure Assy with both
hoists, cables, lower lift cyl pin”
-15.57 (-6.13) 5932 (13077) -164 (-362) 6096 (13439)
Boom Assy w/pivot pins 454.36 (178.88) 10578 (23320) 8547 (18843) 2031 (4477)
Lift Cylinder 347.90 (136.97) 1005 (2216) 622 (1371) 383 (845)
“Complete Basic Machine: Carrier
Ass’y, S/S Ass’y, 6-Section Boom,
Cummins Engine, 445/65R22.5
Michelin Front Tires, 315/80R22.5
Michelin Rear Tires, Full Fuel and
Hydraulic Oil, cable on both hoists”
287.68 (113.26) 36747 (81013) 18800 (41446) 17947 (39567)
Boom Extensions
10.5 - 17.6 m (34.5 - 57.6 ft) Manual
Bi-fold Boom Extension
572.90 (225.55) 1529 (3370) 1557 (3433) -29 (-63)
10.5 - 17.6 m (34.5 - 57.6 ft)
Hydraulic Bi-fold Boom Extension
585.88 (230.66) 1603 (3535) 1671 (3683) -67 (-148)
10.5 - 17.6 m (34.5 - 57.6 ft) Manual
Integrated Heavy-Duty Bi-fold Boom
Extension
584.23 (230.01) 1640 (3615) 1704 (3756) -64 (-141)
10.5 - 17.6 m (34.5 - 57.6 ft)
Hydraulic Integrated Heavy-Duty Bi-
fold Boom Extension
595.86 (234.59) 1715 (3780) 1817 (4006) -103 (-226)
Boom Extension Carrier Brackets 460.15 (181.16) 190 (419) 156 (343) 34 (76)
Boom Extension Carrier Brackets for
Integrated Heavy Duty Extensions
458.50 (180.51) 200 (441) 163 (360) 37 (81)
Hose Reel for Hydraulic Boom
Extension
849.10 (334.29) 201 (443) 303 (669) -103 (-226)
Aux Boom Nose 1014.10 (399.25) 86 (190) 155 (342) -69 (-152)
Counterweights
3000 lb counterweight (pin on with
pins) on S/S
-246.05 (-96.87) 1369 (3019) -599 (-1321) 1969 (4340)
5000 lb counterweight (pin on with
pins) on S/S
-246.05 (-96.87) 2277 (5019) -996 (-2196) 3273 (7215)
5000 lb counterweight (pin on with
pins) on S/S
-246.05 (-96.87) 2277 (5019) -996 (-2196) 3273 (7215)
