OPERATING PROCEDURES TMS9000-2 OPERATOR MANUAL
4-24
Published 02-21-2019, Control # 611-05
3000 lb counterweight (pin on with
pins) on S/S
-246.05 (-96.87) 1369 (3019) -599 (-1321) 1969 (4340)
2000 lb counterweight (pin on) on S/
S
-246.05 (-96.87) 907 (2000) -397 (-875) 1304 (2875)
3000 lb counterweight (pin on with
pins) on carrier deck
481.97 (189.75) 1369 (3019) 1174 (2588) 196 (431)
3000 lb counterweight (pin on with
pins) on carrier deck
481.97 (189.75) 1369 (3019) 1174 (2588) 196 (431)
2000 lb counterweight (pin on) on
carrier deck
481.97 (189.75) 907 (2000) 777 (1714) 130 (286)
3000 lb counterweight (tray) on
carrier deck
481.97 (189.75) 1361 (3000) 1166 (2571) 195 (429)
5000 lb counterweight (pin on with
pins) on carrier deck
481.97 (189.75) 2277 (5019) 1951 (4302) 325 (717)
10000 lb counterweight (non pin on)
on carrier deck
481.97 (189.75) 4536 (10000) 3888 (8571) 648 (1429)
Rigging Equipment
11 t (12.1 ton) Overhaul Ball (Swivel)
- in stowage tray
830.58 (327.00) 294 (648) 435 (958) -140 (-309)
11 t (12.1 ton) Overhaul Ball (Swivel)
- tied to front bumper
942.34 (371.00) 294 (648) 493 (1086) -199 (-438)
26 t (28.7 ton) Hookblock (1 sheave)
- tied to front bumper
955.04 (376.00) 323 (712) 549 (1210) -225 (-497)
45 t (49.6 ton) Hookblock (3 sheave)
- tied to front bumper
955.04 (376.00) 450 (992) 764 (1685) -314 (-693)
60 t (66.1 ton) Hookblock (5 sheave)
- tied to front bumper
955.04 (376.00) 565 (1245) 959 (2114) -394 (-869)
91 t (100 ton) Hookblock (5 sheave)
- tied to front bumper
955.04 (376.00) 658 (1451) 1118 (2464) -459 (-1013)
Rigging 170.18 (67.00) 45 (100) 14 (30) 32 (70)
Cribbing (in rear troughs) -35.56 (-14.00) 181 (400) -11 (-25) 193 (425)
Optional Equipment
Driver 762.00 (300.00) 113 (250) 154 (339) -40 (-89)
Rear Frame Counterweight Mount -187.96 (-74.00) 53 (116) -18 (-39) 70 (155)
Trailing Boom - Carrier Components -83.82 (-33.00) 33 (73) -5 (-11) 38 (84)
Trailing Boom Brackets (use with
trailing boom w/dolly option)
822.40 (323.78) 87 (192) 127 (281) -40 (-89)
Substitutions and Removals
SUB: Main Hoist Only (replace aux
hoist and cable with IPO cwt)
-271.91 (-107.05) -342 (-754) 166 (365) -508 (-1119)
“REM: Main Hoist Cable (820’ of 3/
4”” Bridon Dyform 34LR)”
-176.91 (-69.65) -483 (-1065) 152 (335) -635 (-1400)
“REM: Aux Hoist Cable (581’ of 3/4””
Bridon Dyform 34LR)”
-271.91 (-107.05) -342 (-754) 166 (365) -508 (-1119)
Axle Weight Distribution Table
