OPERATING PROCEDURES TMS9000-2 OPERATOR MANUAL
4-22
Published 02-21-2019, Control # 611-05
Requirements and recommendations regarding operation
and use of Grove Cranes are stated on decals and in this
Operator Manual and other manuals provided with each
specific model machine.
The crane owner must make sure that all personnel working
on and around the crane are properly trained and thoroughly
familiar with operational functions of the crane and safe
operating and work practices. Personnel should be
thoroughly familiar with regulations and standards governing
cranes and their operation. Work practices may vary slightly
between government regulations, industry standards, local
and job-site rules and employer policies so a thorough
knowledge of and compliance with all relevant work rules is
necessary.
Table 2 Continued
Driving Rigged Crane Balanced Axle Load on Firm, Level Surface 57.6 ft. (17.56 m) Boom Extension Erected at 0°
Offset Angle Headache Ball Reeved Over Extension, 3-Sheave Hook Block Removed
Counterweight
(LBS.)
Superstructure
Position
Main
Boom
Angle
(°)
Main
Boom
Length
(ft.)
Boom Configuration Front
Axle
Loads
(LBS.)
Rear
Axle
Loads
(LBS.)
Tele 1 Tele 2 Tele 3 Tele 4 Tele 5
16,000 Over Front 24 49.3 0 0 0 0 50 26,300 26,200
18,000* Over Front 17 49.3 0 0 0 0 50 26,800 26,700
26,000 Over Front 18 50.2 50 0 0 0 0 28,700 28,800
36,000
Over Front 24 63.8 50 50 0 0 0 31,200 31,300
Over Rear 81.5 36.6 0 0 0 0 0 34,500 28,200
48,500
Over Front 14 77.2 50 50 50 0 0 34,500 34,400
Over Rear 65 36.6 0 0 0 0 0 34,500 34,500
Table 2 Continued
Driving Rigged Crane Balanced Axle Load on Firm, Level Surface 83.8 ft. (25.54 m) Insert + Boom Extension
Erected at 0° Offset Angle Headache Ball Reeved Over Extension, 3-Sheave Hook Block Removed
Counterweight
(LBS.)
Superstructure
Position
Main
Boom
Angle
(°)
Main
Boom
Length
(ft.)
Boom Configuration Front
Axle
Loads
(LBS.)
Rear
Axle
Loads
(LBS.)
Tele 1 Tele 2 Tele 3 Tele 4 Tele 5
36,000
Over Front2050.250000031,500 31,600
Over Rear81.536.60000034,200 29,200
48,500
Over Front 19 63.8 50 50 0 0 0 34,700 34,700
Over Rear7036.60000034,900 34,800
