Manitowoc Grove TMS9000-2 Series User Manual

4-21
TMS9000-2 OPERATOR MANUAL OPERATING PROCEDURES
4
Published 02-21-2019, Control # 611-05
GROVE
Table 2
Driving Rigged Crane Balanced Axle Load on Firm, Level Surface Stowed Boom Extension or 11.4 ft. (3.48 m)
Boom Extension Erected at 0° Offset Angle 3-Sheave Hook Block Hanging from Boom Nose or Headache Ball
Reeved Over Extension
Counterweight
(LBS.)
Superstructure
Position
Main
Boom
Angle
(°)
Main
Boom
Length
(ft.)
Boom Configuration Front
Axle
Loads
(LBS.)
Rear Axle
Loads
(LBS.)
Tele
1
Tele
2
Tele
3
Tele
4
Tele
5
16,000
Over Front 40 63.8 50 50 0 0 0 26,400 26,300
Over Rear 81 36.6 0 0 0 0 0 26,400 26,500
18,000*
Over Front 37 63.8 50 50 0 0 0 26,800 26,900
Over Rear 80 36.6 0 0 0 0 0 27,000 26,900
26,000
Over Front 18 63.8 50 50 0 0 0 28,900 28,800
Over Rear 74 36.6 0 0 0 0 0 28,800 29,100
36,000
Over Front 0 77.2 50 50 50 0 0 31,000 31,800
Over Rear 67 36.6 0 0 0 0 0 31,300 31,600
48,500 Over Rear 59 36.6 0 0 0 0 0 34,700 34,500
Table 2 Continued
Driving Rigged Crane Balanced Axle Load on Firm, Level Surface 34.5 ft. (10.52 m) Boom Extension Erected at 0°
Offset Angle Headache Ball Reeved Over Extension, 3-Sheave Hook Block Removed
Counterweight
(LBS.)
Superstructure
Position
Main
Boom
Angle
(°)
Main
Boom
Length
(ft.)
Boom Configuration Front
Axle
Loads
(LBS.)
Rear
Axle
Loads
(LBS.)
Tele 1 Tele 2 Tele 3 Tele 4 Tele 5
16,000 Over Front 35 50.2 50 0 0 0 0 26,000 26,200
18,000* Over Front 32 50.2 50 0 0 0 0 26,500 26,600
26,000
Over Front 34 63.8 50 50 0 0 0 28,500 28,700
Over Rear 81.5 36.6 0 0 0 0 0 29,400 27,100
36,000
Over Front 20 63.8 50 50 50 0 0 31,000 31,800
Over Rear 70 36.6 0 0 0 0 0 31,200 31,200
48,500 Over Rear 62 36.6 0 0 0 0 0 34,300 34,300
