OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL
3-112 Published 02-21-2019, Control # 611-05
4Battery Power
Green = full charge
Amber = discharging
5 Right Motion Command Depicts the operation that is controlled by the right motion command button
6
7
Left Enable
Right Enable
White = neither enable button is depressed (function cannot be operated)
Green = either enable button is depressed (function can be operated)
8DEG or RPM
When appropriate, shows the position of the superstructure in degrees or
the rotational speed of the selected motion.
9E-Stop
White = not active (operation allowed)
Red = active (operation not allowed until E-stop is pulled out)
10 Crane Fault
White = not active (operation allowed)
Red = active (take corrective action as indicated in Crane Operator Manual)
11 Carrier Park Brake
White = brake applied
Red = brake released
12 Carrier Transmission
White = transmission in neutral
Red = transmission in gear (must be in neutral)
13 360° Swing Lock
White = swing LOCK position
Red = swing UNLOCK position
