SET-UP AND INSTALLATION TMS9000-2 OPERATOR MANUAL
6-10
Published 02-21-2019, Control # 611-05
FIGURE 6-15 continued
6453-1
34.5 Ft (10.5 m) FIXED BOOM
EXTENSION SHOWN AT 0
o
OFFSET
57.6 Ft (17.7 m) BI-FOLD BOOM EXTENSION
SHOWN AT 0
o
OFFSET
