Figure 6-19 to determine the correct counterweight
combinations.
To help identify individual counterweight components, the
final weight has been steel stamp on each counterweight in
kilograms and pounds.
Standard Counterweight Combinations
ITEM NUMBER
12345678
WEIGHT (lbs) 3000 5000 10000
3000
Tray
4000
LH
4000
RH
2250
RH
2250
LH
CWT Combinations
6,000 lb 1 1
8,000 lb 1 1
8,000 lb 1 1
11,000 lb 1 1 1
16,000 lb 1 2 1
21,000 lb 1 1 1 1
26,000 lb 1 2 1 1
36,000 lb 1 2 2 1
48,500 lb 1 2 2 1 1 1 1 1
