GROVE 6-29
TMS9000-2 OPERATOR MANUAL SET-UP AND INSTALLATION
Published 02-21-2019, Control # 611-05
Swinging with rigged counterweight
Swinging with a rigged counterweight is only permissible
when:
- the necessary outrigger span is rigged,
- the respective RCL code is shown, and
- the permissible working radius according to Lifting
capacity table is maintained.
The following table specifies (depending on the
counterweight and outrigger span) whether swinging the
superstructure is:
- Permitted
- Only permitted for certain working radii
- Disabled (with the correct rigging mode)
WARNING
Tipping/Overload Hazard!
RCL lockouts and limiters are not functional when remote
control is used.
When operating functions from remote control, operator
must be positioned to see crane movement.
Read the Operator Manual.
