TMS9000-2 OPERATOR MANUAL OPERATING CONTROLS AND INDICATORS
3
1)
For Service personnel only, not suitable for external
devices, e.g. mobile phone
Item Description Refer to
1
ODM screen
Overview of the CCS start
menu
Overview of the CCS menu
groups
page 3-28
page 3-46
2 Jog dial
3
Service/diagnosis
connection
1)
4
Exiting the menu/input
mode
page 3-34
5 Selector buttons page 3-32
6 Alarm Silence
6.1
Operating in the Outrigger
menu
page 3-93
7
Hoist Limit Lockout
Indicator
page 3-99
8 Lighting Sensor page 3-89
9 Input confirmation page 3-35
10 Changing menus page 3-33
11 Switch display page 3-35
12 Not used
13
Sensor temperature
display
page 3-35
