5-2
Remove the bolts and star washers from
the bottom rails of the side panels.
Remove two bolts from each corner brace
in the lower back corners of the washer.
Remove the front panel (See page 4-19).
12.
13.
14.
Remove the cover on the drain valve to
disconnect the ground wire, the common
and L1 then pull them through to the back.
Bundle up the wires and put them outside
the cabinet so they don’t get tangled.
Disconnect the vent tube connected to the
overflow.
10.
11.
Wire
Connectors
Vent Tube
Bottom Rail
Bolt
2 Corner
Brace Bolts
To Next Page
