5-3
Two people will be needed to lift the
cabinet up and off. Lift the cabinet off the
holding pins.
15.
TECH TIP: Before reinstalling the cabinet
onto the washer, the hose from the
dispenser, the air hose from the control
board and the door latch wiring should
be taped to the top of the tub for easier
reassembly.
NOTE: Avoid removing the rails at the base
of the frame unless the rails need to be
replaced. Each rail has two screws, one at
each end.
2 Base Rail
Screws
Excessive Weight Hazard
Use two people to move or install
heavy parts.
Failure to do so can result in back or
other injury.
To Next Page
