VM600 networking manual MAVM600-NET/E 2 - 1
Edition 9 - February 2018
CPUM cards running firmware version 075 or later
CPUM CARD DIRECTORY STRUCTURE AND CONFIGURATION FILES
2 CPUM card directory structure and configuration files
For a networked VM600 rack, the CPUM card contains a number of different files that define
the configuration and operation of the CPUM card and VM600 rack.
This includes a file that provides basic version information, and configuration files for all of
the communication interfaces and protocols supported by a CPUM card (and its associated
IOCN card (optional)) such as Ethernet, Serial, Modbus, PROFIBUS and PROFINET.
The directory structure and configuration files used, such as net.cfg or hosts, depend on
the version of firmware running on a CPUM card.
2.1 CPUM cards running firmware version 075 or later
For CPUM cards running firmware version 075 or later, the directory structure and
configuration files have been improved and reorganised. They are now significantly different
compared to cards running firmware version 074 or earlier, as shown in Table 2-1.
See 6.1.1 CPUM card configuration files for more information on the directory structure and
configuration files for CPUM cards running firmware version 075 or later.
Table 2-1: Evolution of configuration files for CPUM cards
CPUM card firmware version
Description
(type of information)070
or earlier
071 to 074 075 to 080
081
or later
hosts hosts net.cfg
Network adapters (IP addressing)
and default gateway
(version 074 or earlier)
mbcfg.2
mbcfg.3
mbcfg.4
mbcfg.5
mbcfg.tcp
modbusDefault.cfg
Modbus communications.
PROFINET communications
(version 081 or later).
profinet.cfg
Additional PROFINET
communications
tcpip.1
Network adapters, subnetting and
default gateway
(version 074 or earlier)
version.txt Version information
launcher.cfg
Launcher process (for monitoring
all other processes)
ntp.conf NTP server
sysinit Default gateway
uc.cfg Summary information
xmcsrv.cfg XMx16 cards – summary
xmcnn.xml XMx16 card – individual
