9 - 16 VM600 networking manual MAVM600-NET/E
Edition 9 - February 2018
MPC4 card
SETTING UP A MODBUS CONNECTION (CPUM SW VERSION 071 OR LATER)
9.4.3.3 Status register 3 – diagnostic and common status #2
As shown in Table 9-14.
Modbus address: 1144 + ( ( slot - 3 ) * 3 ) + 2.
Modbus function: 03 or 04.
This information is accessed using the “Board status #2” channel as defined in Table A-2
(available at addresses 1146, 1149, 1152, ..., 1180).
9.4.4 Address map
The MPC4 card’s register definitions for Modbus can be found in the address map tables
given in Appendix A: MPC4 Modbus register definitions. The Modbus register starting
addresses can be determined using the information given in the appendix.
Table 9-14: Mapping of card status register 3
Bit Status Meaning when not set (0) Meaning when set (1)
b0 MCR MPC configuration not running MPC configuration running
b1 to bit
15
Not used
