VM600 networking manual MAVM600-NET/E vii
Edition 9 - February 2018
Notes
Standard off-the-shelf versions of the CPUM card run “standard” versions of firmware and are typically pre-configured with a “standard” configuration.
Customer specific versions of the CPUM card typically run “special” versions of firmware that support customer-specific functions and/or are pre-configured with a customer-specific
configuration. Contact Meggitt Sensing Systems for additional information.
In the CPUM ordering number (PNR) column, the letter C indicates the following versions of the CPUM card:
1 Modular CPU card with one Ethernet interface and one serial interface (integral Ethernet and serial communication ports providing 1x RS-232 or RS-485/422 and 1x integral
Ethernet controller).
3 Modular CPU card with two Ethernet interfaces and one serial interface (integral Ethernet and serial communication ports, with an additional Ethernet controller module providing
redundant Ethernet).
4 Modular CPU card with one Ethernet interface and two serial interfaces (integral Ethernet and serial communication ports, with an additional serial communications module
providing redundant RS-485/422).
The change in the CPUM ordering number (PNR) from 200-595-075-C2x to 200-595-076-Dxx corresponds to the CPUM card update in 2015 to use a new PC/104 CPU module
(PFM-541I or equivalent) that supports two Ethernet interfaces by default, which required updates to the underlying carrier board. (Previously, the CPUM card was fitted with a CPU
module (MSM586SEN or equivalent) that supports one Ethernet interface by default and required an additional Ethernet controller module (MSME104 or equivalent) to be fitted in
order to be Ethernet redundant.)
In the CPUM ordering number (PNR) column, the letter D indicates the following versions of the CPUM card:
3 Ethernet redundant versions of the CPUM card, that is, with two Ethernet interfaces (and two serial interfaces).
5 Serial redundant versions of the CPUM card, that is, with two Ethernet interfaces (and two serial interfaces) and two additional serial interfaces.
For an explanation of the Discrete value coded in analog register column, see 8.6.5 Discrete values coded in an analog value register.
CPUM ordering number
(PNR)
Memory
Operating
system
Features
Disk
On
Chip
(MB)
Compact
Flash
(MB)
QNX
version
PPP
protocol
enabled
Modbus
Discrete
value
coded in
analog
register
PROFIBUS PROFINET
VM600 MPS
rack
(CPUM)
security
200-595-61x-C1x
200-595-62x-C1x
16 4.25
200-595-701-C14 32 6.0.3
200-595-703-C2x 512 6.0.3
200-595-724-C2x 512 6.0.3
200-595-72x-C2x
200-595-750-C2x
512 6.4.1
