6 - 2 VM600 networking manual MAVM600-NET/E
Edition 9 - February 2018
About CPUM Configurator
CPUM CONFIGURATOR
See also 2 CPUM card directory structure and configuration files.
Table 6-1: Configuration files for CPUM cards
CPUM card firmware version 075 or later
Configuration file Description
launcher.cfg
Launcher process (for monitoring all other processes):
Configuration information for the launcher process (that
monitors the other processes) running on the CPUM card.
modbusDefault.cfg
Modbus and PROFINET communications:
Configuration information for Modbus and PROFINET
communications, including register mapping information for the
Modbus interface and PROFINET slot information for the
PROFINET interface running on the CPUM card.
profinet.cfg
PROFINET communications:
Additional configuration information for PROFINET
communications, including the device name and gateway for the
PROFINET interface running on the CPUM card.
net.cfg
Network adapters (IP addressing):
Configuration information for the Ethernet interfaces, including
IP address and netmask information (corresponding to the
CPUM TCP-IP Configuration dialog box)
ntp.conf
NTP server:
Configuration information for the local network time protocol
(NTP) server running on the CPUM card.
uc.cfg
Summary information:
Basic information about the complete user configuration
downloaded from a CPUM card (Save UC from CPUM).
xmcnn.xml
XMx16 card – individual:
Configuration information for an XMx16 card installed in slot nn
of the same VM600 rack as the CPUM card that communicates
with the VibroSight Server process running on the CPUM card.
xmcsrv.cfg
XMx16 cards – summary:
Basic information about the configuration of the XMx16 cards
installed in the same VM600 rack as the CPUM card
(corresponding to the XMCSRV Configuration dialog box).
