Real 1:1 Mode
The whole surface of the label is printable.
The label is pushed forward to the tear off edge for tear off (see
the previous section: Selecting the Tear Off Mode) or to the cutter.
After the tear off/cut, the beginning of the next label is drawn
back under the printhead. This reduces the output volume (in
relation to a certain time).
Please note: The material can only be drawn back until it reaches the
front print unit (not as far as the rear print unit).
A
heads (183 mm) occurs in case of single-sheet printing and
after tear off/cutting the last page of a print job. In addition,
the proportion of label length to the distance of the print
heads can have a negative effect. (It is unfavourable, for
example, if the label/format length is only a little shorter or
much longer than the distance of the two print heads.)
Tear off edge or cutter
Label, unprinted
Label, printed
1. Print
2. Print end
3. Feed,
then tear off
/cut
4. Return
Rear
print head
Front
print head
