Microplex LOGIJET TC8 - Page 163

Operator Maintenance 163
__________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
Fig. 8.1.4.a Unlocking the transparent sensor guide (rear printhead unit)
Fig. 8.1.4.b Swivelling the transparent sensor guide upward

Transparent
sensor guide
release lever
Rear printhead
already raised
Top cover
of the printer
Transparent
sensor guide
Rear
printhead
