MIMAKI JV3-160SP User Manual

– 5.48 –
7) Press the
key.
The state of the front cover sensor is shown on
the LCD.
ON: The front cover has been opened.
OFF: The front cover has not been closed.
Step 8) is only for 75SPII , 130SPII and 130SL. For 160SP, go to step 9)
8) Press the key.
Head height sensor condition appear.
Thin: Head sensor low
High:Head sensor up
Press the
FUNCTION
key.
sensor condition and sensor reading value appear.
press
ENTER
to return.
9) Press the
key.
Current status of ink pack sensor is displayed.
The color codes of the cartridges that have run
out of ink are appear.
10) Press the
key.
Current status of ink end sensor is displayed.
The color codes of the cartridges that have run
out of ink are appear.
11) Press the
key.
Current status of power of heater is displayed.
ON: Power on.
OFF: Power off.
Step 12)-13) is only for 75SPII. For 160SP, go to step 14)
12) Press the key.
CG and I/F input condition apeear
13) Press the
key.
CG and I/F input condition apeear
# TEST
HEATER POW : OFF
# SENSOR TEST
FRONT COVER
# TEST
INK END – – – – – –
# TEST
INK PACK – – – – – –
# TEST
HEAD HIGHT
# SENSOR TEST
CGIF IN :ON/ON
# SENSOR TEST
CGIF OUT :ON/ON
# TEST
HEAD HIGHT :Thin 0 x 00A0)
