FOREWORD
This maintenance manual explains items required for the field maintenance work of JV3-75SPII /
130SPII/130SL/160SP color ink jet plotter.
Maintenance work should be carried out by serviceperson who have learned disassembly, assembly
and adjustment techniques with required tools and measuring apparatus.
This manual covers existing maintenance parts. For any failure other than those described in this
manual, factory-repairs will be necessary.
Before reading this maintenance manual, read the following manual to learn basic operations of the
main unit.
• Setup Guide for JV3-75SPII/ JV3-130SPII(D201087)
• Operation Manual for JV3-75SPII/ JV3-130SPII (D201090)
• Setup Guide for JV3-130SL (D201426)
• Operation Manual for JV3-130SL (D201427)
• Setup Guide for JV3-160SP (D200926)
• Operation Manual for JV3-160SP (D200913)
