6 - 22 Operator’s Manual
6 Image Acquisition
• Destruct Time: Adjust the destruct time.
Dual Live
In live mode or freeze mode, set [Dual Live] as “ON” to enable dual live function. Both the contrast
mode and tissue mode are displayed. The THI and B image are displayed on the screen if the [Dual
Live] is enabled.
Use [CEUS Pos: XX] to adjust the position of the contrast image.
When it is selected as “Left”, the image displays at the left part of the image area on the screen.
• In dual live mode, the screen displays the contrast image and tissue image
• In freeze mode, there displays only one cine review progress bar as the contrast image and
tissue image are reviewed synchronously.
Mix Map
This function is to mix the contrast image with the tissue image, so that interested contrast regions
can be located.
Use [Mix] to select different mixing mode.
• When dual live function is on, you can see the mixed effect on the contrast image.
• When dual live function is off, you can see the mixed effect on the full screen image.
Select the map through the [Mix Map] item.
iTouch
On contrast status, you can also get a better image effect by using iTouch function.
1. Select the iTouch button to turn on the function.
The symbol of iTouch will be displayed in the image parameter area once.
2. Select different levels of iTouch effect through [iTouch] parameter.
3. Select and hold the iTouch button to exit the function.
6.13.4 Image Saving
• Live capture
In live mode, you can save the interested images by selecting [Pro Capture] and [Retro
Capture].
• Cine saving
In live mode, select the Freeze button to enter cine review status.
Tap [Save Clip] at the bottom of the operating panel.
6.13.5 Micro Flow Enhancement
MFE superimposes and processes multiple frames of contrast image during the cycle; it indicates
tiny vessel structures in detail by recording and imaging microbubbles.
• MFE imaging is available only for real-time imaging or cine file of auto review mode. If a
MFE cine is reviewed manually, MFE effect cannot be displayed.
• In MFE status, patient should lie down and hold breath, and transducer should be kept still.
