4 - 4 Operator’s Manual
4 Setup
4.1.4 Measure
Controls are as follows:
Type Item Description
Reset
Config.
Probe To set the default probe model for the
system.
Use the default set-ting when start a new
exam
After it is ticked, when the exam of a
new patient is started, image parameters
will be preset parameters.
Probe/Exam
mode
MITI To set MI TI indexes displayed for
current probe/exam mode.
Freeze Con-
fig
Status after Freeze To set the system status after the image
is frozen.
Image Steer To set the steer mode in B + Color + PW
imaging mode.
• C&PW: select to adjust the sample
volume in color mode and sample
line in PW mode together.
• C/PW: select to adjust the sample
volume in color mode and sample
line in PW mode separately.
Auto Invert The spectrum can automatically invert
when the color flow is steered to a
certain angle, thus accommodating the
operator's wish to distinguish the flow
direction.
B+Color Refresh with PW/CW Sam-
pling Line Movement
To set whether to turn on the function
that when moving PW/CW sampling
line, B image is activated under
B+Color+PW/CW mode.
Full Image (Linear) After it is ticked, if a linear probe is used
and the depth value is low, the image
will be displayed completely.
iScape Ruler Display To set if the caliper is displayed on the
iScape view image.
Display Probe SN To set if the probe SN is displayed next
to the probe model.
Item Description
Cursor Type Type of cursor displayed on the measurement caliper and results
window. Value options:
• Number: the cursor always displays as “+” while different
measurements are marked with numbers.
• Symbol: the cursor displays sequentially in 8 symbols to identify
different measurements.
Cursor Size The size of the cursor.
