B - 2 Operator’s Manual
B Wireless LAN
B.1 Use the Wireless feature
Perform the following procedure:
1. Tap icon to open the wireless network manager.
2. Tap to select the target network, tap [Connect] to connect to the network.
When connecting an encrypted network, enter the password in the box first. You can select to
hide password characters or not.
3. The system tries to connect to the selected network. The icon turns into after successful
connection.
4. Tap [Refresh] to refresh the “Wireless Network Connection” list.
B.2 IP Configure
• When the system background is processing network task (DICOM sending for example),
please do not enter network setting to change the IP, otherwise the background task may fail.
You can check if there are tasks undergoing in the task manager.
• If the IP address displays as 0.0.0.0, this means that the network is abnormal. The reason for
the failure may be disconnection or the system cannot obtain the IP address.
IP config is used for setting local network parameters, which is also applied to DICOM connection.
Perform the following procedure:
1. In Wireless network manager screen, tap [IP Config] to open the configuration page.
– If “DHCP” is selected, the IP address will be automatically obtained from the DNS server.
Tap [Refresh] to check current IP address.
– If “Static” is selected (using a static IP address), enter the IP address.
IP address of the system should be in the same network segment with the server.
Subnet Mask: set different network segment.
Gateway: set the gateway IP.
Host Name: displays the machine name of the system, if changed, the system should be
restarted.
2. Tap [Save] to save current setting or tap [Cancel] to exit.
B.3 EAP Network
For setting EAP network, contact Mindray Customer Service Department or the sales
representatives.
