Mindray TE9 User Manual

2 System Overview
Operator’s Manual 2 - 15
2. Enter the name in the box after “To” to assign a name for a user-defined exam mode.
3. Tap [Save] to save the current image parameters for the user-defined exam mode.
Check image parameter and change layout
Perform the following procedure:
1. Tap [Edit] in the image menu to enter the screen for checking the current image menu display
for the current exam mode of the particular probe.
2. Tap and hold any parameter until it floats, then you can:
– Drag upwards/downwards to change its position on the image menu;
– Drag leftwards/rightwards to change its display on the image menu: drag it to the left
“Options” list to delete its display or drag it to the right “Selected” list to display the
parameter.
3. Tap [Save] to save the settings or tap [Cancel] to cancel changes you made.
2.10.7 Annotations and Body Marks
No. Name Function
1.
Arrow button Tap to add arrow a comment to the image.
2.
Keyboard button
Tap to activate the soft keyboard to type the alphanumeric
characters.
1
2
3
8
5
6
7
4
