3 - 8 Operator’s Manual
3 System Preparation
3.6.2 Disconnecting a probe
Perform the following procedure:
1. Turn the locking lever to the right position to unlock the connector.
2. Pull the probe connector straight out as shown in the figure.
3.7 Connecting USB Devices
DO NOT directly remove a USB memory device, as the USB device and/or the
system may become damaged.
• When connecting a USB memory device to the ultrasound system via a USB port, a sound is
heard if it is connected successfully and the USB icon appears in the system icons area.
• To remove the USB device: tap the USB icon to open the [Remove USB Device] screen. Select
the device to be removed and tap [OK]. A sound is heard when removing the USB memory
device.
• The system supports option of external DVD R/W drive. The DVD R/W drive is connected to
the ultrasound system via USB port.
• When connecting an external DVD R/W drive, connect the two cables of the drive to the
ultrasound system or USB ports on the trolley if the drive provides 2 USB power cables. In this
way, the DVD R/W drive can work more normally.
• If the USB disk cannot be recognized by the system, please try disconnecting and then
connecting again several times, or try another USB disk. If the problem still exists, please
contact Mindray service engineer.
