A Barcode Reader
Operator’s Manual A - 9
A.2.2 Setting Up the Digital Imager Reader
Installing the Interface Cable
Perform the following procedure:
1. Plug the interface cable modular connector into the cable interface port on the bottom of the
reader handle and ensure the connector is properly secure.
2. Connect the other end of the interface cable to the host.
Removing the Interface Cable
Perform the following procedure:
1. Using the tip of a screwdriver or some other tools with a sharp head, depress the cable’s
modular connector clip.
2. Carefully slide out the cable.
A.2.3 Setting
The reader has factory settings, refer to the following table for parameter defaults:
Parameter Defaults Parameter Defaults
1-D Symbologies Interleaved 2 of 5 (ITF)
