2 - 20 Operator’s Manual
2 System Overview
After freezing an image, the system may enter cine review, measure, comment adding, body mark
mode or current mode, depending on what has been preset.
Tap [UnFreeze] in freeze mode to unfreeze the image, and the system continues image scanning.
2.10.13Imaging Mode Switching When Frozen
Imaging mode switching in freeze mode follows these principles:
• In splitting display B mode, tap each image window to switch between the windows.
• In freeze mode, the system supports imaging mode switching between the sub-modes (only for
the activated window). For example, if the frozen image is in B+Color+PW mode, the system
supports imaging mode switching between B+Color+PW, B+Color, B+PW and B by tapping
[Color] or [PW].
2.11 Cine Review
After tapping [Freeze], the system allows you to review and edit the images prior to the image
being frozen. This function is called cine review. You can perform zoom, measurements, add
comments and body marks on the images being reviewed.
The system supports manual review as well as automatic review.
In addition, the system supports the images reviewed along with physiological waveforms, if the
detection of physiological waveforms is performed.
• Cine Review images can be inadvertently combined in-between separate
patient scans. The Cine Review memory must be cleared at the end of the
current patient exam and before starting the next new patient exam by
tapping [End] in the bottom-left corner of the control panel.
• Cine files stored in the system's hard drive should contain patient
information, to avoid the selection of an incorrect image file and potential
misdiagnosis.
2.11.1 Entering/Exiting Cine Review
To Enter Cine Review
• Enter [Setup] > [System]> [Image] > “Freeze Config” screen to set “Status after Freeze” to
“Cine.” The system enters manual cine review status once [Freeze] is tapped.
• Open cine files in Review screen. The system enters automatic cine review status.
Under cine review status, cine review control bar will be displayed on the cine menu.
