Mindray TE9 User Manual

12 Probes and Biopsy
Operator’s Manual 12 - 41
NGB-035 Metal-needle detachable needle-guided bracket
Perform the following procedure:
1. Install the needle-guided bracket:
1 Angle locking nut
2 Angle adjusting block
3 Buckle
4Clamp
5 The clamping nut of left/right clamp
6 The locating position block
7Groove
8 V-shaped guiding block
9 The Pressing block for separating needle
10 Needle guide hole
11 Needle clamping cover of needle guided bracket
12 Needle adjusting nut of needle-guided bracket
13 Angle adjusting base
14 Angle mark
1
14
13
12
11
10
8
9
7
4
5
6
3
2
