14-5-2. Relay zone
1) Remote input
4 stations occupied (Master → CSD-892-73)
Device No. Contents Classification
RYn0 ① Setting value writing request (Request 1)
Communication
RYn1
RYn2 ② General command request (Request 2)
RYn3 ③ Selection of writing/Reading out. (R/W)
RYn4 ④ Operation mode changeover request (Request 3)
RYn5
RYn6
RYn7
RYn8
RYn9
RYnA
RYnB
RYnC
RYnD
RYnE
RYnF
RY(n+1)0 ⑤ ZERO
Control signal
RY(n+1)1 ⑥ ZERO Clear
RY(n+1)2 ⑦ Tare weight cancellation
RY(n+1)3
⑧ Tare weight cancellation clear
RY(n+1)4 ⑨ Hold
RY(n+1)5 ⑩ Net display
RY(n+1)6 ⑪ Gross display
RY(n+1)7
RY(n+1)8
RY(n+1)9
RY(n+1)A ⑫ Error cancellation request flag
RY(n+1)B
RY(n+1)C
RY(n+1)D
RY(n+1)E
RY(n+1)F
RY(n+2)0
RY(n+2)1
RY(n+2)2
~
RY(n+7)0
System reservation flag
RY(n+7)1
RY(n+7)2
RY(n+7)3
RY(n+7)4
RY(n+7)5
RY(n+7)6
RY(n+7)7
RY(n+7)8
RY(n+7)9 ⑬ Initialed data setting request flag
RY(n+7)A ⑭ Error reset requesting flag
RY(n+7)B
RY(n+7
)C
RY(n+7)D
RY(n+7)E
RY(n+7)F
n : Value decided by setting of station No.
