2 stations occupied (Master → CSD-892-73)

Device No. Contents Classiﬁcation

RYn0 ① Setting value writing request (Request 1)

Communication

RYn1

RYn2 ② General command request (Request 2)

RYn3 ③ Selection of writing/Reading out. (R/W)

RYn4 ④ Operation mode changeover request (Request 3)

RYn5

RYn6

RYn7

RYn8

RYn9

RYnA

RYnB

RYnC

RYnD

RYnE

RYnF

RY(n+1)0 ⑤ ZERO

Control signal

RY(n+1)1 ⑥ ZERO Clear

RY(n+1)2 ⑦ Tare weight cancellation

RY(n+1)3

⑧ Tare weight cancellation clear

RY(n+1)4 ⑨ Hold

RY(n+1)5 ⑩ Net display

RY(n+1)6 ⑪ Gross display

RY(n+1)7

RY(n+1)8

RY(n+1)9

RY(n+1)A ⑫ Error cancellation request ﬂag

RY(n+1)B

RY(n+1)C

RY(n+1)D

RY(n+1)E

RY(n+1)F ⑮ Indicate value changeover ﬂag (Net value/Gross value)

RY(n+2)0

RY(n+2)1

RY(n+2)2

RY(n+3)0

System reservation ﬂag

RY(n+3)1

RY(n+3)2

RY(n+3)3

RY(n+3)4

RY(n+3)5

RY(n+3)6

RY(n+3)7

RY(n+3)8

RY(n+3)9 ⑬ Initialed data setting reques

t ﬂag

RY(n+3)A ⑭ Error reset requesting ﬂag

RY(n+3)B

RY(n+3)C

RY(n+3)D

RY(n+3)E

RY(n+3)F

n : Value decided by setting of station No.
