① Setting value writing response (Response 1)
The finish of writing by the Setting value writing request (Request 1) is notified.
ON ：In completion or writing
OFF ：After confirming OFF of Setting value writing request (Request 1).
② General command response (Response 2)
The finish of writing by the Setting value writing request (Request 2) is notified.
ON ：In completion or writing
OFF ：After confirming O
FF of Setting value writing request (Request 2).
③ Writing / Reading out selection response (R/W response)
The condition of writing/reading out by command order is notified in the notification by the
general command response (Response 2).
ON ：Reading out
OFF ：Writing
④ Operation mode changeover request (Request 3)
The finish of changing operation mode by Operation mode changeover request (Request 3)
is
notified. This function is a extension facility, and CSD-892-73 cannot used this function.
ON ：In the completion of the changeover
OFF ：After confirming OFF of the Operation mode changeover (Request 3).
⑤ CPU normal operation
CC-Link interface operating normally is notified.
ON → OFF → ON reversing is notified at 0.5 seconds interval.
⑥ Decimal point display position 1, 2 and 4
The decimal point position of the load value is notified by the 3 bits binary.
Decimal point
position
Decimal point position 1 Decimal point position 2 Decimal point position 4
0 (None) OFF OFF OFF
0.0 ON OFF OFF
0.00 OFF ON OFF
0.000 ON ON OFF
0.0000 OFF OFF ON
• A temporary delay occurs in CPU normal operation signal while memorizing various
set values and while executing memory clearness.
