⑦ Near ZERO, and the other condition
The conditions of NEAR ZERO, FULL FLOW/S1, MEDIUM FLOW/S2, DRIBBLE FLOW/
S3, PROPER VALUE/S0, UNDER, STABLE and FULL are notified.
⑧ Weighing capacity over
This signal is notified when the abnormal condition occurs in the load (OL, OVF, -OL or
-OVF).
ON ：In the occurrence of abnormal condition
OFF ：Normal
⑨ During HOLD
The hold condition either of [Display], [Comparison result], [Gross/Net value of CC-Link
interface] is notified.
ON ：During HOLD
OFF ：Free running
⑩ Abnormal weight
Weighing capacity over, or ZERO set error is notified.
ON ：In the occurrence of abnormal error
OFF ：Normal
⑪ Initial data setting completion flag
CSD-892-73 is not available. Even if the flag is turned on, data is not initialized.
ON ：In the completion of setting
OFF ：Normal
⑫ Error condition flag
The occurrence of the error in CSD-892-73 is notified.
ON ：In the occurrence of the error
OFF ：Normal
⑬ Remote READY
Completing initialization and possible to communicate is notified.
ON ：Possible to communicate
OFF ：In the initialization
99
