① Change of calibration mode
Shift to the calibration mode after writing the data showing below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9001 0
Error that cannot be executed
The following code is set when executing by other than the measurement mode.
Condition Error code Error assistance code
Condition that cannot be executed. 99 2
② Setting of UNIT
The UNIT is set by writing the data in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9020
UNIT Setting value
Nothing 0
g 1
kg 2
t 3
lb 4
N 5
kN 6
Pa 7
KPa 8
MPa 9
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Error assistance code
Setting range error 99 1
Error that cannot be executed
The following code is set when executing by other than the calibration mode, or not
setting it according to the flow chart in [14-6.].
Condition Error code Error assistance code
Condition that cannot be executed. 99 2
101
CC-Link
To Next Page
