⑨ ZERO calibration by numeric input
The load cell output value is registered as ZERO after writing the data in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9008
Setting range : -25 000 ~ 25 000
TE-L error
When the read load cell output value is below than -2.5 mV/V and exceeds over the ZERO
adjustment range at minus side, the following code is set.
Condition Error code Error assistance code
TE-L error 4 0
TE-H error
When the read load cell output value is over than 2.5 mV/V and exceeds over the ZERO
adjustment range at plus side, the following code is set.
Condition Error code Error assistance code
TE-H error 4 1
Error that cannot be executed
The following code is set when executing by other than the calibration mode, or not setting it
according to the flow chart in [14-6.].
Condition Error code Error assistance code
Error that cannot be executed. 99 2
⑩ Confirmation of SPAN stability (Actual load)
* Please execute in the same manner of [Confirmation of ZERO stability. (Actual load)
The condition of STABLE/UNSTABLE is reading out after setting the data in the below table.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9006
Optional
The read condition of STABLE/UNSTABLE is set as follows:
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9006
0 : UNSTABLE
1 : STABLE
Error that cannot be executed
The following code is set when executing by other than the calibration mode.
Condition Error code Error assistance code
Error that cannot be executed. 99 2
105
CC-Link
