⑦ Confirmation of ZERO stability (Actual weight)
The condition of STABLE/UNSTABLE is reading out after setting the data in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9006
Optional
The condition of STABLE/UNSTABLE read out is set in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9006
0 : UNSTABLE
1 : STABLE
Error that cannot be executed
The following code is set when executing by other than the calibration mode.
Condition Error code Error assistance code
Error that cannot be executed. 99 0
⑧ ZERO calibration by measurement value
The load cell output value is registered as ZERO after writing the data in the table below.
When the data other than [0] are written in the general data area, the signal becomes an
error outside a set range. (Error code : 99, Error assistance code : 1)
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD)
(RWwn4~RWwn5)
9007
0
TE-L error
When the read load cell output value is below than -2.5 mV/V and exceeds over ZERO
adjustment range at minus side, the following code is set.
Condition Error code Error assistance code
TE-L error 4 0
TE-H error
When the read load cell output value is over than 2.5 mV/V and exceeds over ZERO
adjustment range at plus side, the following code is set.
Condition Error code Error assistance code
TE-H error 4 1
Error that cannot be executed
The following code is set when executing by other than the calibration mode, or not setting it
according to the flow chart in [14-6.].
Condition Error code Error assistance code
Error that cannot be executed. 99 2
104
