⑤ Setting of weighing capacity
The maximum display value is set by writing the data in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9003
Setting range : 1 ~ 99999
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Error assistance code
Setting range error 99 1
Error that cannot be executed
The following code is set when executing by other than the calibration mode, or not setting it
according to the flow chart in [14-6.].
Condition Error code Error assistance code
Error that cannot be executed. 99 2
⑥ Setting of mass of weight
The mass of weight is set by writing the data in the table below.
Command No.
(RWwnE) : 4 stations are occupied.
(RWwn6) : 2 stations are occupied.
General data area
(RWwnC~RWwnD) : 4 stations are occupied.
(RWwn4~RWwn5) : 2 stations are occupied.
9004
Setting range : 1 ~ 99999
However, below the maximum display value.
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Error assistance code
Setting range error 99 1
Error that cannot be executed
The following code is set when executing by other than the calibration mode, or not setting it
according to the flow chart in [14-6.].
Condition Error code Error assistance code
Error that cannot be executed. 99 2
103
