Table of reading out command
Command name Command Number Return command set value
Digital filter 70 01 001 ~ 512 (Unit : Moving average time 1 time)
Analog filter 70 02 0: 2 Hz, 1: 4 Hz, 2: 6 Hz, 3: 8 Hz, 4: 10 Hz
Stabilization filter 70 05 001 ~ 512 (Unit : moving average time 1 time)
Stabilization filter data width 70 06 0000 ~ 9999 (Unit : 0.1D)
Stabilization filter time width 70 07 00 ~ 99 (Unit : 0.1 s)
Individual key lock 70 08
0000 ~ 1111 (0 : Invali
d, 1 : Valid)
10
0
digit : F/ENTER key
10
1
digit : CAL-S/ ▲ key
10
2
digit : CAL-Z/ key
10
3
digit : FUNC. key
Stability detection data width 70 10 000 ~ 999 (Unit : 0.1D)
Stability detection time width 70 11 00 ~ 99 (Unit : 0.1 s)
Hold target 70 17
000 ~ 111 (0 : Invalid, 1 : Valid)
10
0
digit : Output of CC-Link interface
10
1
digit : Comparative output
10
2
digit : Display
5-steps comparator operation
target
70 21
00000 ~ 22222 (0: Display interlock, 1: Gross, 2: Net)
10
0
digit : S0 operation target
10
1
digit : S1 operation target
10
2
digit : S2 operation target
10
3
digit : S3 operation target
10
4
digit : S4 operation target
5-steps comparator operation
condition
70 22
00000 ~ 22222 (0: OFF, 1: OVER, 2: UNDER)
10
0
digit : S0 operation
10
1
digit : S1 operation
10
2
digit : S2 operation
10
3
digit : S3 operation
10
4
digit : S4 operation
Comparator hysteresis operation
condition
70 24 0 : On-delay, 1
: Off-delay
Comparator hysteresis data width 70 25 00 ~ 99 (Unit : 1D)
Comparator hysteresis time width 70 26 00 ~ 99 (Unit : 0.1 s)
USB (RS-232C) operation mode 70 40 0 : Command mode, 1 : Stream mode
USB (RS-232C) output target
in stream mode
70 41
0 : Display interlock, 1 : Gross, 2 : Net
3 : Load display data with condition
Specifications of USB (RS-232C)
communication
70 42
0000 ~ 15121
10
0
digit : Data bit length 0 : 7 bit, 1 : 8 bit
10
1
digit : Parity 0 = No parity, 1 = Even, 2 = Odd
10
2
digit : Stop bit 0 = 1 bit, 1 = 2 bit
10
3
digit : Baud rate 0 = 1 200 bps, 1 = 2 400 bps,
2 = 4 800 bps, 3 = 9 600 bps, 4 = 19 200 bps,
5 = 38 400 bps
10
4
digit : Terminator 0 = CR, 1 = CR+LF
USB (RS-232C) transmission data
with decimal point
70 46 0 : No decimal point, 1 : With decimal point
USB (RS-232C) digit of unit 70 49 0 : Unit 2 digit, 1 : Unit 3 digit
• Please change [7*] in the above mentioned command part to [8*] at the time of
writing.
• The number of 40 ~ 49 is only reading because these relates to the transmission
setting.
121
