Command name Command Number Return command set value
Operation of F/ENTER key 70 55
0 : No use, 1 : Hold, 2 : ZERO set, 3 : ZERO clear,
4 : Tare weight cancellation clear, 5 : Tare weight
cancellation clear, 6 : Change of NET/GROSS,
7 : Shift to comparator setting mode
External control input
INPUT1 operation
70 60
00 : OFF, 01 : ZERO set, 02 : ZERO clear,
03 : Tare weight cancellation, 04 : Tare weight
ca
ncellation clear, 05 : Change of NET/GROSS,
06 : Hold (Pulse), 07 : Hold (Level), 08 : Net value
display (Level : When gross weight is displayed, the
net amount is displayed by turning on.), 09 : Batch key
lock (Level : Effective in turning on at the measurement
screen.), 10 : Error release
External control input
INPUT2 operation
70 61 Selectable as well as F-60.
External control input
INPUT3 operati
on
70 62 Selectable as well as F-60.
External control output
OUTPUT1 operation
70 70
00 : OFF, 01 : Stable, 02 : During tare weight
cancellation, 03 : Gross display, 04 : Net display,
05 : Center ZERO, 06 : During HOLD, 07 : ERROR, 08
: Abnormal weight, 09 : Near Zero, 10 : OK (S0), 11 :
FULL FLOW (S1), 12 : MEDIUM FLOW (S2),
13 : DRIBBLE FLOW (S3), 14 : OVER (S4),
15 : UNDER, 16 : FULL, 17 : RUN (dur
ing
measurement)
External control output
OUTPUT2 operation
70 71 Selectable as well as F-70.
External control output
OUTPUT3 operation
70 72 Selectable as well as F-70.
External control output
OUTPUT4 operation
70 73 Selectable as well as F-70.
External control output
OUTPUT5 operation
70 74 Selectable as well as F-70.
External control output
OUTPUT logic
70 83
00000 ~ 11111 (0 : Negative logic, 1 : Positive logic)
1
0
0
digit : OUTPUT1 operation
10
1
digit : OUTPUT2 operation
10
2
digit : OUTPUT3 operation
10
3
digit : OUTPUT4 operation
10
4
digit : OUTPUT5 operation
Occupied station of CC-Link
interface
70 84
0 : Occupied 1 station, 1 : Occupied 2 stations,
2 : Occupied 4 stations
Station number of CC-Link
interface
70 85
01 ~ 64 at F-84 = 0, 01 ~ 63 at F-84 = 1,
01 ~ 61 at F-84 = 2
Baud rate of CC-Link interface 70 86
0 :
156 kbps, 1 : 625 kbps, 2 : 2.5 Mbps, 3 : 5 Mbps,
4 : 10 Mbps
32 bit data expression method of
CC-Link interface
70 87
0 : Standard binary expression,
1 : Most significant bit sign
Date of maintenance 70 90 Do not use.
Maintenance number 70 91 Do not use.
Liquid crystal backlight ON time 70 95 00 ~ 60 (Unit : minute)
• Please change [7*] in the above mentioned command part to [8*] at the time of
writing.
122
