11-2-2. Set items of single comparison mode
Item Set data number Setting value Contents
FINAL SET1
00000 ~ 99999
● 00000
Unit : 1D
FREE FALL SET2
00000 ~ 99999
● 00000
Unit : 1D
PRELIMINARY 1 SET3
00000 ~ 99999
● 00000
Unit : 1D
PRELIMINARY 2 SET4
00000 ~ 99999
● 00000
Unit : 1D
OVER SET5
00000 ~ 99999
● 00000
Unit : 1D
UNDER SET6
00000 ~ 99999
● 00000
Unit : 1D
NEAR ZERO
(ZERO BAND)
SET7
00000 ~ 99999
● 00000
Unit : 1D
FULL SET8
00000 ~ 99999
● 00000
Unit : 1D
● : Default
FINAL
The target value of measurement is set by set data number SET1.
Setting range：00000 ～ 99999
：00000
Unit：1D
FREE FALL
The value of FREE FALL is set by set data number SET2.
The output of dribble flow is turned on when the measurement result reaches to [FINAL(SET1)
- FREE FALL(SET2)].
Setting range：-99999 ～ 99999
：00000
Unit : 1D
PRELIMINARY 1
The value of PRELIMINARY 1 is set by set data number SET3.
The output of medium flow is turned on when the measurement result reaches to
[FINAL(SET1) - PRELIMINARY1(SET3)].
Setting range : 00000 ～ 99999
：00000
Unit : 1D
PRELIMINARY 2
The value of PRELIMINARY 2 is set by set data number SET4.
The output of full flow is turned on when the measurement result reaches to [FINAL(SET1) -
PRELIMINARY2(SET4)].
Setting range : 00000 ～ 99999
：00000
Unit : 1D
OVER
The value of OVER is set by set data number set5.
The output of OVER is turned ON when the measurement result exceeds [FINAL(SET1) -
OVER(SET5)]
Setting range : 00000 ～ 99999
：00000
Unit : 1D
63
Setting of Comparator
