About SMB Controller
As soon as pattern [5] is showed, the start-up phase is completed, and the SMB Controller is
in normal mode. You are able to log into the SMB Controller Manager. The MiVoice Business
application software is now starting up and after a while you are able to log in to MiVoice
Business.
2.2.4.2 Normal Mode
The SMB Controller is in normal mode when the SMB Controller system software is up and
running without error. The LED combination pattern [6] is displayed.
If there is a problem with the temperature inside the housing of the SMB Controller (overheating)
and/or a problem with the fan, it is signaled with the PWR LED turning from green to orange
(pattern[7]). Details of the problem can be found in the SMB Controller Manager.
If applications are loaded and running, there might be some additional information available,
indicated with the LED F0 - F6. Each LED is assigned to an application. The F0 LED is assigned
to the MiVoice Business application:
• If the F0 LED lights up orange (pattern [8]), the default IP address is active.
• If the F0 LED lights up red (pattern [9]), there is an error in the MiVoice Business
application.
Table 8: Normal mode with additional information
No. PWR F0 F1 F2 F3 F4 F5 F6 SYS Meaning
[6] Normal mode,
SMB Controller
is up and
running.
[7] Normal mode,
overheating.
Details in the
SMB Controller
Manager.
[8] Normal mode,
default fixed
IP address is
active.
Document Version 1.0
17 System Manual for Mitel SMB Controller
