4 - 20
4.6 Offset/Gain Settings
4.6.2 Offset/gain settings (Q66AD-DG)
4
SETUP AND PROCEDURES BEFORE OPERATION
*1 The mode switching (normal mode to offset/gain setting mode to normal mode) method is given
below.
Dedicated instruction (G(P).OFFGAN) .......................... Refer to Section 4.6.2 (2) (a)
Setting made to mode switching setting (Un\G158, Un\G159) and turning the operation
condition setting request (Y9) from OFF to ON ........ Refer to Section 4.6.2 (2) (b)
Intelligent function module switch setting ............. ... Refer to Section 4.5, Section 4.6.2 (2) (c)
(After intelligent function module switch setting, reset the programmable controller CPU or
switch power OFF, then
ON.)
*2 Turning ON the channel change request (YB) starts to supply power from the corresponding
channel to the 2-wire transmitter. After fully checking the wiring, settings, etc., turn ON the chan-
nel change request (YB).
*3 Do not perform the following during the operation (*3 in the above flow chart). Doing so may
cause malfunction of the Q66AD-DG because of a data error in the flash memory.
Power-off of the system
Reset of the programmable controller CPU
To Next Page
