8 Settings via the MICT
Rev. 03/2019 105
Energy Limit
You can use the field Energy Limit to limit the output energy made available by the ignition
controller. If the set output energy is no longer sufficient to reach the set energy values (spark
duration, spark intensity, max. breakdown voltage), the spark duration is reduced
correspondingly.
Required supply voltage for energy control
Depending on the output configuration and the energy settings, for a
correct energy control, a higher supply voltage than the minimum 10 V DC
sufficient for operation of the device can be necessary. If this is the case,
the required supply voltage is displayed in a notice in the window Timing –
Schedule A/B – Energy.
8.11.9 Timing – Miscellaneous
You can specify how fast the changes of the timing should be executed.
