6.2.4 Straight Order Wiring of the Ignition Outputs – Overview
MIC5
The following table contains the allocation of the MIC5 outputs to the cylinders.
Output In-line engine V-engine
Connector* Coil** Connector* Coil**
Output A1 1 1 1 1
Output B1 1 2 2 1
Output A2 1 3 1 2
Output B2 1 4 2 2
Output A3 1 5 1 3
Output B3 1 6 2 3
Output A4 1 7 1 4
Output B4 1 8 2 4
Output A5 1 9 1 5
Output B5 1 10 2 5
Output A6 1 11 1 6
Output B6 1 12 2 6
Output A7 1 13 1 7
Output B7 1 14 2 7
Output A8 1 15 1 8
Output B8 1 16 2 8
Output A9 1 17 1 9
Output B9 1 18 2 9
Output A10 1 19 1 10
Output B10 1 20 2 10
Ground
Connector* = connector on the wiring rail
Coil** = ignition coil with the corresponding number on the wiring rail
