Page #58 background imageLoading...
Page #58 background image
6 Wiring of the Device
58 Rev. 03/2019
MIC5-SE
The following table contains the allocation of the MIC5-SE outputs to the cylinders.
Output In-line engine V-engine
Connector* Coil** Connector* Coil**
Output A1 1 1 1 1
Output A2 1 2 2 1
Output A3 1 3 1 2
Output A4 1 4 2 2
Output A5 1 5 1 3
Output A6 1 6 2 3
Output A7 1 7 1 4
Output A8 1 8 2 4
Ground
Connector* = connector on the wiring rail
Coil** = ignition coil with the corresponding number on the wiring rail
