6 Wiring of the Device
Rev. 03/2019
51
6.1.8
Output Wiring – RS485 Interface
The RS485 interfac
e can be wired as two-wi
re or four-wire wi
ring and twisted cab
les must be
used. With both variants the load resistance (R
T
=120 Ω) is the characteristic impedance of
the
cable.
Two-Wire Wiring
First device
Last device
Second device
Second-to-last device
Four-Wire Wiring
First device
(Master)
Last device
(Slave)
Second device
(Slave)
Second-to-last device
(Slave)
